S9PRO Troubleshooting Guide

S9PRO

Troubleshooting- Start now

S9PRO

Troubleshooting- Start now

S9PRO Installation Guide

S9PRO Display Error Code Definitions

Error Code	Description	Troubleshooting Method
E04	Short Circuit Failure	Check for wiring short circuit or installation issues. Replace the controller if needed.
E06	Abnormal Meter Power Supply Voltage	Replace the meter.
E10	Controller/Instrument Communication Failure	Replace both the dashboard and the controller.
E11	Motor Phase A Current Sensor Failure	Replace the controller.
E12	Motor Phase B Current Sensor Failure	Replace the controller.
E13	Motor Phase C Current Sensor Failure	Replace the controller.
E15	Brake Failure	Replace the brake lever.
E16	Motor Hall Failure	Replace the motor (front wheel).
E57	Motor Temperature Control Alert	Check and reconnect the white temperature control wire between the motor and controller. If the issue persists, reflash the firmware or replace the controller.

Q1: The tail light stays on but doesn’t flash when braking

A1: If the brake handle has been reset and the error still appears after unplugging and reconnecting the wiring, replace the brake handle.

Q2: The charger shows green, but the battery is not fully charged

A2: Replace the battery.

Q3: Rear wheel brake makes noise

A3: Adjust the brake assembly. Refer to the video:

https://youtu.be/571KKX8WWKM

Q4: Rear brake failure

A4: Adjust the brake assembly. Refer to the video:

https://youtu.be/su3wNP9V8XI

Q5: The front wheel and handlebar cannot align

A5: Adjust the riser to the wheel. Refer to the video:

https://youtu.be/3O92Du6OwSU

Q6: The folding mechanism is too tight or too loose

A6: Adjust the folding lock. Clockwise to loosen, counterclockwise to tighten. For a loose stem, turn counterclockwise.

Q10: Unable to power on

A10: It is normal that the device cannot power on while charging. Try turning it on when not charging.

If the charger indicator flashes red and green alternately, replace the charger.

If the red light stays on during charging, the battery is normal and the controller should be replaced.

If the green light stays on from the beginning, the battery may be faulty and should be replaced.

Q11: Unable to connect to the app

A11: Make sure phone location services are enabled.

Ensure the app is correctly installed.

Try a different phone, as some may have compatibility issues.

If the issue persists, replace the instrument panel.

Q12: Scooter shuts off while riding

A12: If the charger shows green immediately when plugged in, test the battery and charger voltage. If not possible, replace the battery.

Q13: Unable to turn off

A13: If the headlight switch and gear position can be adjusted normally, replace the meter.

If not, replace the controller.

Q14: The headlights cannot be turned off

A14: Replace the controller.

Q15: Why is the frame not horizontal

A15: The frame is intentionally designed to be higher in the front and lower in the rear. This brings the handlebar closer to the rider and improves riding comfort and control.

Q16: The handlebar turn signal is broken

A16: This is usually caused by user damage. It does not affect normal riding. The signal light can be replaced if necessary.

Q17: The thermometer icon on the instrument is flashing or always on and affects riding

A17: The motor naturally heats up during use.

When the temperature reaches 100 degrees Celsius, the thermometer icon flashes and the controller limits current, reducing power.

At 110 degrees Celsius, the icon stays on and the scooter stops working.

After cooling, the scooter can be used again.

This is a protection mechanism to prevent motor damage from overheating. If the customer cannot accept this feature, you may discuss unplugging the white temperature control wire.
